Single Head Full Automatic Capping Machine

+
  • 主图(4).jpg

категория:

Пресс-пресс.

категория:

Linear Capping Machine

Automatic Single Head Capping Machine is controlled by PLC and equipped with photo electricity instruction and pneumatic action.

Automatic Single Head Capping Machine is controlled by PLC and equipped with photo electricity instruction and pneumatic action.

Описание продукции

The machine used straight bottle feeding and control by PLC program . Bottles will be fixed by two cylinders and it can automatically arrange lid , taking lid and sending lid,it will first grasp lid then capping under control of double-acting cylinder lifting stroke. The machine grasp lids through pneumatic type, lid-revolving head has a clutch to ensure the



main technical parameter

Capacity ≤700b/h
applicable bottle diameter ≤320(L)×220(W)mm
applicable bottle height 250-450mm
cap diameter ≤75mm
air pressure 0.6-0.8Mpa
voltage AC380V,50/60Hz
total power 2Kw
net weight 400kg
dimension 2000(L)×1030(W)×2100(H)mm
